Harvia Cilindro Wood-Burning Sauna Stove (16 and 20)

A stainless pillar of stones with a real fire behind glass.

Recommended sauna size 212–459 cu ft (6–13 m³), by Harvia’s rating Glass or stone walls? Use the Heater Finder

No electrical control needed

Choose a model Cilindro Wood 16

Cilindro Wood 16 Rooms 212–459 cu ft Cilindro Wood 20 Rooms 282–706 cu ft

Complete your setup

Add stones, a chimney kit and extras now so everything arrives together.

Optional

Protective floor bedding

Harvia WL110 Protective Bedding 560 x 636 mm +$437.00

No protective bedding

System total

$1,382.00 CAD before tax

Nothing to pay now. We confirm stock, shipping and your total before you pay. How ordering works

The cart needs JavaScript. Turn it on, or email us at info@lakeshoresaunas.ca to order.

Questions about sizing, chimneys or delivery? Email info@lakeshoresaunas.ca Send a message Mon–Fri 9 am–6 pm, Sat 10 am–4 pm ET

Overview

About the Harvia Cilindro

The Harvia Cilindro wood-burning sauna stove brings the pillar look of Harvia's electric Cilindro to a real wood fire. A stainless outer shell holds 120 kg of stones around the firebox, so you get long, soft steam that carries on after the flames settle. Its glass door, set in a cast-iron frame, lets the glow into the room, and it can be hung to open either way.

The Cilindro 16 is rated for 6–13 m³ (212–459 cu ft) and the Cilindro 20 for 8–20 m³ (282–706 cu ft), with rated outputs of 16 and 17 kW. A ventilation duct at the back speeds up heating, and replaceable air-control plates protect the firebox and extend its life. It's a strong fit for cottages, cabins and backyard saunas across Canada.

Plan the chimney first: both models have a 115 mm flue outlet on the top or back and need a chimney kit matched to it, which is sold separately. Keep Harvia's clearances to combustible walls (about 150 mm at the sides and 200 mm at the back), and set it on a non-combustible floor.

Models compared

Every Harvia Cilindro model side by side. Pick one to see its full specifications and add-ons.

Harvia Cilindro Wood-Burning Sauna Stove: models compared
Model	Room size	Stones	Price (CAD)	Select
Cilindro Wood 16	212–459 cu ft (6–13 m³)	120 kg	$1,382.00
Cilindro Wood 20	282–706 cu ft (8–20 m³)	120 kg	$1,721.00

Room sizes are the manufacturer’s ratings; glass, stone or log walls need more power, so check with the Heater Finder. Prices in CAD, before tax.

Specifications

Showing: Cilindro Wood 16 Change

Harvia Cilindro Wood-Burning Sauna Stove, Cilindro Wood 16: specifications
Recommended sauna size	212–459 cu ft (6–13 m³) Harvia’s rating. Glass, stone or log walls need a bigger heater, so use the Heater Finder.
Control	None needed (wood-burning)
Stones	About 120 kg (265 lb) of 10–15 cm stones, sold separately
Dimensions	557 × 557 × 750 mm (W × D × H) 21.9 × 21.9 × 29.5 in (W × D × H)
Weight	54 kg (119 lb)
Flue outlet	115 mm (4.5 in)
Maximum log length	35 cm (14 in)
Clearances	Sides 150 mm (5.9 in) · back 200 mm (7.9 in) · front 500 mm (19.7 in) · ceiling 1,000 mm (39.4 in) Minimum distances to combustible surfaces, per the manufacturer.
Mounting	Floor
Model code	WKPC16S
Good to know	Rated output 16 kW.
Warranty	2 years for residential use.
Certification	CE marked
Made in	Finland

Harvia Cilindro Wood-Burning Sauna Stove, Cilindro Wood 20: specifications
Recommended sauna size	282–706 cu ft (8–20 m³) Harvia’s rating. Glass, stone or log walls need a bigger heater, so use the Heater Finder.
Control	None needed (wood-burning)
Stones	About 120 kg (265 lb) of 10–15 cm stones, sold separately
Dimensions	557 × 557 × 773 mm (W × D × H) 21.9 × 21.9 × 30.4 in (W × D × H)
Weight	62 kg (137 lb)
Flue outlet	115 mm (4.5 in)
Maximum log length	39 cm (15 in)
Clearances	Sides 150 mm (5.9 in) · back 200 mm (7.9 in) · front 500 mm (19.7 in) · ceiling 1,000 mm (39.4 in) Minimum distances to combustible surfaces, per the manufacturer.
Mounting	Floor
Model code	WKPC20S
Good to know	Rated output 17 kW.
Warranty	2 years for residential use.
Certification	CE marked
Made in	Finland

What you need to install it

Needs a chimney kit matched to the 115 mm flue outlet, installed to the chimney maker's instructions.
Keep the manual's clearances to walls, benches and ceiling, and set the stove on a non-combustible floor or base.
Harvia lists 150 mm (5.9 in) at the sides, 200 mm (7.9 in) at the back, 500 mm (19.7 in) in front and 1,000 mm (39.4 in) to the ceiling from combustible materials.
Many home insurers ask for a WETT inspection, so book one before the first fire.

Stones: Holds about 120 kg (265 lb) of 10–15 cm stones. Sold separately.

Documents

Manuals and spec sheets from Harvia.

Documents are hosted by Harvia and can change without notice; your electrician or installer works from the manual that ships with the product. Need a document in another format? Ask us.

How ordering works

No card details online. You pay only after you have approved a written invoice.

Step 1: Send your order request

Add products to your cart and send the request. Nothing is charged, and you’re not committed to buy.
Step 2: We confirm stock, shipping and your total

We check availability and shipping to your address, then email a written invoice with every cost, including tax.
Step 3: You approve the invoice and pay

Read it, ask questions, then approve and pay by Interac e-Transfer or credit card. Nothing is charged before you say yes.
Step 4: We ship your order

In-stock items ship in 3–5 business days after payment; special-order items take 3–6 weeks. We deliver anywhere in Canada.

Harvia Cilindro questions

Cilindro 16 or 20?

The 16 suits rooms of 6–13 m³ (212–459 cu ft); the 20 suits 8–20 m³ (282–706 cu ft). Add about 1.2 m³ for each square metre of glass or bare masonry, and multiply by 1.5 for a log-walled sauna.

Is a chimney included?

No. The stove has a 115 mm flue outlet on the top or back, and you'll need a chimney kit sized to it, plus any adapter for a 6 in chimney system.

How long can the logs be?

Up to about 35 cm for the Cilindro 16 and 39 cm for the Cilindro 20, per Harvia's manuals. Split wood 8–15 cm across works best.

Can I use it in an outdoor barrel or cabin sauna?

Yes, that's what it's made for. Keep the listed clearances, protect the floor and follow the chimney maker's instructions for going through the roof or wall.
